Midi Spike Spot

This LED spike light is smaller than most standard spike lights out there yet packs a huge punch!
With upto 1100 lumens available, this fitting is suitable for illumining large features.
During the day it will blend within the planting, but at night it opens up a whole new world of colour to your outdoor project.
Submersible (IP68)
Small, but powerful with a user-replaceable 6W Cree LED.
10 year guarantee.

Dimmable.
Reverse polarity and over current protection up to 100V DC.
Safe for children and adults alike - no risk of electric shock.
All components of the fitting are replaceable allowing for longevity of the fitting beyond the warranty for years to come.

Must be used with 350mA LED drivers, wired in series only. 42W Max (120VDC)

IP Rating	IP68
Standard LED	6.6W
Standard Cable	2.00m

Installation Guide

This fixture works from 350mA constant current LED drivers wired in series (not standard parallel). The driver should be purchased separately and can power a mixture of different lights together from the same driver. We recommend sizing the circuit to a maximum total LED wattage of 35W per circuit. The driver can be up to 1km from the last light. For lengths of cable over 200m you should consult the cable calculator.

This fixture is rated IP68, meaning it is fully waterproof and suitable for submerged installation.
